TMS-C500 Ext & S-Cart500 for loads
up to 500 kg

See the S-Cart1500
solution here

S-Cart500W

A shelf cart developed to pick up, transport and drop off loads of up to 500 kg/1100 lbs, in free space, when combined with the ROEQ TMS-C500 Ext top module and the MiR250.

Robot compatibility:
MiR250

ROEQ product compatibility:
TMS-C500 Ext, TMS-C300 Ext, S-Cart Rails

Payload:
Up to 500 kg/1102 lbs with ROEQ TMS-C500 Ext top module.
Up to 300 kg/661 lbs with ROEQ TMS-C300 Ext top module.
For high payloads please contact your ROEQ Partner for best practice.

Size (l x w x h): 790 x 800 x 423 mm/31.1″ x 31.5″ x 16.7″

• Middle wheels for better maneuverability

• Pick up and drop off in free space

• Attachment holes in the corners for attaching customized equipment

• Comes with one ESD wheel as standard

S-Cart500 Ext

A shelf cart developed to pick up, transport and drop off loads of up to 500 kg/1100 lbs, in free space, when combined with the ROEQ TMS-C500 Ext top module and the MiR250. The increased wheelbase gives increased tilt stability for longer goods.

Robot compatibility:
MiR250

ROEQ product compatibility:
TMS-C500 Ext, TMS-C300 Ext, S-Cart Rails

Payload:
Up to 500 kg/1102 lbs with ROEQ TMS-C500 Ext top module.
Up to 300 kg/661 lbs with ROEQ TMS-C300 Ext top module.
For high payloads please contact your ROEQ Partner for best practice.

Size (l x w x h): 790 x 800 x 423 mm/31.1″ x 31.5″ x 16.7″

Length of Wheelbase: 1000 mm/39.4″

• Increased wheelbase -> increased tilt stability

• Designed for transport of longer goods

• Middle wheels for better maneuverability

• Pick up and drop off in free space

• Attachment holes in the corners for attaching customized equipment

• Comes with one ESD wheel as standard

S-Cart Rails

The set of rails can be used to transport US pallets and EU pallets. They are adjustable to accommodate both pallet types and they ensure the pallet remains in place during transport.

ROEQ product compatibility:
S-Cart1500W, S-Cart500 series, S-Cart300 series

S-Cart300

Robot compatibility:
MiR250, MiR Shelf Carrier 250 TM

ROEQ product compatibility:
TMS-C300 Ext, Rails (Euro pallets and US stringer-type pallets)

Payload: up to 300kg/661Ibs

For high payloads please contact your ROEQ Partner for guidance.

Size (l x w x h): 790mm x 800mm x 423mm/31.1″ x 31.5″ x 16.7″

• Works without docking stations.

• Pick-up and drop-off in free space.

• Attachment holes in the corners for attaching customized equipment

S-Cart1500W

The ROEQ S-Cart1500W is a heavy-duty cart that can take loads of up to 1500kg/ 3307lbs. It is designed to work with the ROEQ TMS-C1500 top module on the large MiR robots (MiR1000 and MiR1350). Note: it can also work with the MiR500 and MiR600 with a payload of 800kg/1764lbs.

Robot compatibility:
MiR500, MiR600, MiR1000, MiR1350

ROEQ product compatibility:
TMS-C1500, S-Cart Rails

Payload:
Up to 1500kg/3307lbs
Up to 800kg/1764lbs if used with MiR500 or MiR600

Size (l x w x h): 1300 x 1235 x 474mm/ 51.2 x 48.6 x 18.7”

Thread size: 4 x M10

Attachment holes: 1250 x 1175mm/ 49.21 x 46.26”

• Can transport up to 1500kg

• Large cargo area for large loads – e.g. stringer-type US pallets

• Can be manually operated by personnel

• Attachment holes for third party equipment

• Six wheels for increased tilt stability

• Rails can be easily attached for transport of US and Euro pallets
